Lagoon NSF-Certified Melt Blown Filter Cartridges – Precision Filtration, Proven Quality

Lagoon Melt Blown Filter Cartridges Manufacturer & Supplier

mmp manufactures and supplies Lagoon Melt Blown Filter Cartridges designed for reliable depth filtration in water purification and liquid filtration applications. Virgin polypropylene cartridges are manufactured using a three-layer gradient, which offers increasing capture for varying-sized particles, allowing for a higher level of consistent filtration. The Lagoon Cartridges are available in 5” – 50”, 1 micron – 100 micron, with Jumbo versions up to 114 mm in diameter.

mmp possesses over 30 years of filtration knowledge, serving customers with an international reach and a local focus (USA, Italy). Providing filtration solutions for water and industrial applications ranging from melt blown, wound, pleated, spun, and other cartridge technologies.

Lagoon Melt Blown Filter Cartridges
Technical Name Melt Blown Filter Cartridges (medium density)
Raw Material
  • Virgin Polypropylene
ID
  • 20-35mm±
OD
  • 50-63mm± 1mm Jumbo 114± 2mm
Length
  • 5”-50” 127mm to 1778mm
Microns
  • 1-100µ
Construction
  • Polypropylene fibres are extruded through tiny perforations under pressure and high temperature on a rotating mandrel, forming three layers for gradient filtration.
Flow
  • 1m³ per hour per 10” at pressure of 2.5Kg/cm²
Temperature
  • Max. 60° C

The Lagoon Melt Blown Filter Cartridge is manufactured using virgin polypropylene fibers that are heated and extruded through fine perforations onto a rotating mandrel. This yields a threefold gradation within the filter's density structure. The finest impurities will remain on the surface of the filter, while the thicker layers would take bigger grains.

This type of depth-filter has the advantage of distributing the particle loading to the entire cartridge, not just the surface. They are manufactured from 1 to 100 m and available in sizes 5” to 50” and standard OD’s approx 50-63 mm, with a jumbo option of up to 114 mm OD. A flow rate of 1 m/hour is achieved per 10” cartridge at 2.5 kg/cm. Maximum temperature is 60°C.

  • Virgin Polypropylene Construction: Manufactured using virgin polypropylene for consistent filtration performance and product quality.
  • Three-Layer Gradient Filtration: The layered structure progressively captures larger and smaller particles through the depth of the cartridge.
  • Wide Micron Range: Available in filtration ratings from 1 to 100 µm, allowing selection according to the required filtration level.
  • Multiple Length Options: Available in lengths from 5” to 50”, with Jumbo configurations for higher filtration requirements.
  • Consistent Flow Performance: Delivers a specified flow rate of 1 m³/hour per 10” cartridge at 2.5 kg/cm².
  • Lightweight Construction: The cartridge design provides a practical filtration solution without adding unnecessary weight to the filtration system.
  • NSF-Certified Range: mmp states that its Lagoon cartridges are NSF-certified, supporting their use where certified filtration products are required.

The melt blown polypropylene filter construction of Lagoon cartridges makes them suitable for applications where depth filtration is required to reduce suspended particles and sediment from liquids.

  • Drinking Water Filtration: Suitable for water purification systems where consistent sediment and particulate removal is required.
  • Domestic Water Purification: Can be used in household filtration and purification applications.
  • Commercial Water Filtration: Supports filtration requirements in commercial water treatment systems.
  • RO Pre-Filtration: Can be used as a preliminary filtration stage to reduce particulate loading before downstream treatment.
  • General Liquid Filtration: The available micron range allows the cartridge to be selected for different particulate-removal requirements.

FAQs About Lagoon Melt Blown Filter Cartridges

Yes. Lagoon is a melt blown water filter made from virgin polypropylene and designed for water filtration applications. mmp states that the Lagoon range is NSF-certified and can be used for household water purification and other water filtration requirements.

Lagoon melt blown polypropylene filter cartridges are available in lengths from 5” to 50”. Standard outer diameters are approximately 50–63 mm, while Jumbo cartridges are available up to 114 mm. Micron ratings range from 1 to 100 µm.

According to the technical specifications on mmp’s product page, Lagoon melt blown polypropylene filter cartridges have a maximum operating temperature of 60°C. Operating conditions should be checked against the specific filtration system before selection.

There is no fixed replacement interval for a melt blown polypropylene filter cartridge. Service life depends on factors such as water quality, contaminant load, micron rating, flow rate and operating conditions. The cartridge should be replaced when filtration performance or flow begins to decline.

mmp has an established international presence and states that it serves customers across 25 countries, with global filtration operations and international offices. Its website also provides dedicated international product and market pages. For availability of the specific Lagoon range in a particular country, customers can contact mmp directly.
