Wound Filter Cartridges | MMP Filtration

Hydro-wound cartridges are designed for versatile filtration with material options like Polypropylene, Polyester, and Cotton yarn. Tailored for your choice with various lengths and micron preferences.

Technical Name	Wound Filter Cartridges
Core	Polypropylene Stainless Steel Core Tinned Steel Core Melt Blown Polypropylene
Yarn	Polypropylene Polyester Cotton Nylon Rayon Glass Fibre
ID	28mm ± 0.5mm
OD	Standard: 63mm ± Jumbo: 114mm
Length	5″, 10″, 20″, 30″, 40″ & 50″
Microns	0.5, 1, 5, 10, 25, 50, 75 & 100µ Nominal
Temperature	60° C to 200° C
Flow	1m³ per hour per 10” at line pressure of 3.5 Kg/cm²
